KLQ6770G
Bus Model |
KLQ6770G (7.7METER) TWO STEP |
Seats |
22+1 |
||||
Dimension |
mm |
7749 x 2340 x 3050 |
Max speed |
km/h |
90 |
Manufacturer’s max. total mass |
kg |
11150 |
Kerb mass |
kg |
7570 |
Rated fuel consumption |
Fuel tank |
L |
220L |
||
Overhang front / rear |
1840/2590 |
Wheelbase |
L |
3600 |
Standard Chassis |
|
Engine |
Chinese Yuchai YC4G180-40 (180Ps, Euro IV) , rear located, with turbo charger, Chinese III emission standard |
Clutch |
Sachs clutch |
Gearbox |
China Qijiang QJ705 five forward gear manual gearbox |
Transmission shaft |
Strengten propeller shaft |
Suspension |
Leaf spring suspension front 6 and rear 9 leaves with shock absorber and stabilizer. |
Axle |
Fangsheng front & rear drums brake, automatic slack adjuster |
Brake |
Dual-circuit service brake, spring energy parking brake WABCO ABS |
Steering |
Chinese Power steering |
Tyres |
8R22.5 tyre |
Others |
Stainless steel wheel cover with ABS sensor Without Retarder |
Standard Body |
|
A/C |
Standard AC(22000 Kcal, BOCK compressor) Roof mounted, Un-independent |
Seats |
Plastic seat; cloth; Back Rest Tilt Adjustable & Sideways Adjustable seats; all seat should have seat belt |
Passenger door |
Remote control |
Windows |
Seal window glass, Rear window has a sliding glass; Clear glass |
Lamps |
Step lamps; inner roof lamps; |
Floor |
Gray color PVC |
Others |
2 roof hatch with ventilating fan, 1 manual sun visor in the front (at driver side), digital clock, Electric control; 2kg fire extinguisher quantity 1; Solid paint |
Note : The manufacturer reserves the right to change the technical specs for better improvement without prior notice.
