KLQ6123K (12 METERS)



p1  p2  p1


Bus Model

KLQ6123K (12 METERS)

Standard seats number

49+1+1

Overall dimensions

mm

12000x2550x3820

Max. speed

km/h

120

Manufacturer’s max. total mass

kg

18000

Kerb mass

kg

13500

Fuel consumption per 100km

L

<26L

Fuel tank

L

360L

Overhang front/rear

L

<2450/3400mm

STANDARD CHASSIS

Engine

YC6L330-42  engine (330Ps, Euro 4)

Clutch

SACHS Clutch

Gearbox

China Qijiang QJS6-160 six forward gear manual gearbox

Propeller shaft

Strengthen propeller shaft

Suspension

Air suspension

Axle

Fangsheng front and rear axle

Braking

Dual circuits service brake; spring energy parking brake. Electric retarder (Terca brand) ; Imported slack adjustor; THELMA retarder and WABCO ABS.

Steering

ZF Power steering gear

Tyre

Chinese brand tire 295/80R22.5

Others

Stainless steel wheel cover with ABS sensor

STANDARD BODY

A/C

32000kCal/h, Bock compressor

Seats

BA02

Door

Remote control

Window

Seal window glass, Rer window has a sliding glass, clear glass

Audiovisual

G-BOS Video (2x19’ TV : front and middle);

Rear-view

Electric rear view mirrors ; Rearview monitor

Floor

Anti-attrition floor leatheriod

Others

Manual sun visor; Color reverse camera (G-BOS: CCTV); Cloth folding window curtain; luggage rack with cover; 2 emergency roof exit; Rear-view; Automatic fire extinguisher device in engine compartment; Safety hammer; 2KG fire extinguisher

Note :  The manufacturer reserves the right to change the technical specs for better improvement without prior notice.
